· Two stitched print heads with print height up to 50 mm and max 20 lines

· Weighs 860g only, ultra flexible and smooth coding with built-in encoder design

· One printer for dual use. Take in hand for mobile coding and mount on production line for auto coding

· Simple and intuitive user interface fast get started, no special training needed usage.

Specification

Product Model
B40

Print Height
2.5mm-50mm (1-20 lines)

Optional Ink Cartridges
Water based (42ml*2)?Black, Cyan, Magenta, Yellow Solvent Based (42ml*2)?Black, Cyan, Magenta, Yellow, White, Green

Optional Ink Cartridges
Water based (42ml*2)?Black,Magenta,Yellow,Cyan,Green Solvent Based (42ml*2)?Black,White,Magenta,Yellow,Cyan, Green,Security

Printing Technology
Thermal Inkjet (TIJ?

Ink Throw Distance
2-5mm?Distance between nozzle plate and print object?

Operation System
Linux based

System Language
Chinese/ English/ German/ Arabic/ Spanish/ Russian/ Japanese/ Korean/ Italian/ Portuguese/ French/ Hindi/ Thai/ Vietnamese/ Persian/ Turkish/ Chinese Traditional/ Indonesian/ Slovenian / Serbo-Croatian/ Czech/ Bulgarian/ Romanian/ Polish/ Greek/ Hungarian/ Ukrainian/ Slovak/ Burmese (Avaialbe languages vary for different regions)

Display
5" High Definition Touch Screen

Status Alarm
Green: Ready Blue: Printing Red: Alarm

Print Applications
Text, Numbers, Images, Logos, 2Dcodes, Barcodes, Dates, Counter, Database etc.

Printable Materials
Waterbased inks for Porous and semi porous substrates: Paper/ Corrugated box/ Wooden/ Fiberboard/ Cotton etc.

Solvent based inks for semi porous and non porous substrates: Plastic/ Glass/ Metal plates/ Alu foils/ Cables etc.

Barcode Type
Code128, Code39, EAN8, EAN13, UPCA, ITF(2of5)

2D code Type
DateMatrix, QR codes

Font Type
True type fonts, Dotmatrix fonts

Resolution
300dpi

Max. Print Size
50mm*2000mm

Max. Pixel Size
Standard 566px*12800px

Print speed
15m/ min

Grey level
1-10 Adjustable

External Ports
USB, Type-C, Power adapter, Photoelectric Sensor, Encoder, Beacon

Power Adapter
Input? AC100-240V, 50/60Hz Output: DC9.3V-5A

Working Environment Recommended
Working Temperature: 5-35? Storage Temperature: 0-45? Relative Humidity: 10%-80%

Battery
6000mAH

Standby Time
≥8 hours (working when screen off)

Memory Size
4 Gigabytes

Net Weight
860g

Packaging Weight
3.5kg(Aluminum case)

Product Dimension
220*110*75mm

Packaging Dimension
378*178*270mm
